Winter Innovation Magazine January 2022

BREAK NE W GROUND Innovation Magazine January 2022

THE L AT EST INNOVATION L AYOU T & MEASURING PM 20-CG Combi-lasers BREAKERS & BITS TE 3000-AVR Heavy-duty electric jackhammer ANCHORS & FASTENING HIT-HY 200-A/R V3 Adhesive anchor TE-YX Hammer drill bits Wire hanger system FIRESTOP SOLUTIONS CFP-ES Endo-Shield endothermic mat CS-S SA Light smoke and acoustic sealant SOFTWARE & SERVICES ON!Track 3.0 Field Request Module Hilti Smart PROFIS Engineering

THE L AT EST INNOVATION

we want to hear from you LEVEL UP WITH MAXIMUM VERSATILITY Help take the guesswork out of your jobsite with the PM 20-CG Combi-lasers. PM 20-CG Combi-laser Engineered to help tackle all your measuring needs, the PM 20-CG combi-laser’s crisp green beams offer best in class v isibility a nd u ltimate v ersatility f or al l y our l ayout a nd installation needs. Align reference points, and transfer points overhead, and help ensure your job is level and square all with the PM 20 — reducing the chance of jobsite e rrors. PM 20-CG A12 Combi-laser With long run times, fast charging and minimal set up, experience less downtime and more productivity with the PM 20-CG A12. Designed as an easy to use, self-leveling compact pocket laser with multiple modes, the PM 20-CG A12 brings versatility and dependability to virtually any layout work. PM 20-CGE Combi-laser For the most critical of tasks requiring high tolerances, the PM 20-CGE provides the ultimate laser precision with a +/- .12 inch accuracy at 33 feet, for plumbing, leveling, aligning and squaring jobs. Item # 2322751 Item # 2322752 Item # 3767565

TOOL FLEET MANAGEMENT 2 YEAR WEAR AND TEAR COVERAGE 20 YEAR LIMITED WARRANTY 1 DAY REPAIR TURNAROUND Tool warranty. Some limitations apply. Contact Hilti for details. APPLICATIONS AND ADVANTAGES • B etter visibility up to 66 ft — green beam makes for easier indoor use and in bright light for transferring position and fastening points overhead • H igh-speed layout — compact, self-leveling cross line laser with magnetic bracket so you can get started with minimal setup time • U p to 5 days of continuous layout work per charge with the PM-20-CG A12 — powered by the same batteries as your other Hilti 12V tools • B uilt for the toughest of jobsite conditions — IP 54 rated protection against dust and moisture, and Class 2 laser which requires no special precautionary measures • O ut-of-level and low-battery alerts — help prevent mistakes and unexpected downtime • H igh precision with the PM 20-CGE — for vertical alignment of elevator rails, leveling and aligning elevator doors and façade elements Technical data Accuracy +/- .12 inch at 33 feet Max operating distance (lines) 131 ft Max operating distance with receiver (lines) 328 ft Self-leveling range at room temperature 4° Self-leveling time 3 sec Horizontal fan angle 200° Vertical fan angle 160° IP protection class IP 54 (EN 60529) Laser type Green line and point Laser class < 1 mW, 510-530 nm, Class 2 (IEC 60825-1:2008), Class II (FDA CFR 21 art. 1040) Accessories Description Item number PMA 20 Tripod 411287 PMA 90 Wall mount 2227009 PMA 89 Magnetic bracket 2227008 PMA 32 Receiver 2264046 PMA 93 Crab-clamp 2232984 PMA 91 High foot 2204575 PMA 92 Anti-fall cable 2239886 PMA 62 Case 2283290

BR EA KTHROUGH W ITH I NNO VATION TE 3 000 He avy-duty e lectric j ackhammer with Active Vibration Reduction (AVR) The highest demolition performance of all Hilti breakers and on par with 90lb air hammers, the new TE 3000-AVR heavy-duty electric jackhammer delivers faster and virtually effortless concrete demolition to your j obsite — all you need is the tool, chisel and power cord. T ake advantage of the entire breaking solution by pairing it with the new TE-H chisel line. Designed to withstand and enhance t he upgraded power and performance of the TE 3000-AVR the improved mul tiline TE-H chisel portfolio amplifies your imp act. The newly innovated TE 3000-AVR not only packs a 40% increase in power with six pounds less weight, but is also o utfitte d wit h a quic k relea se chuck , enablin g yo u t o switch out y our ch is els m ore s wiftly a n d e fficientl y. APPLICATIONS AND ADV ANTAGES • Complete medium to heavy-duty demolition of r einforced concr ete slabs and foundations with the TE 3000-AVR solution • Rem oval of concrete for rebar connections and utility connections with less weight and more power • S treamlined way of digging and tamping in eart hwork wit h the TE 3000-AVR and TE-H chisel • With accessories and inserts tailored to your s pecific applications, you ca n easily accessorize the TE 3000-AVR to meet your needs • Detachable, universal supply cord for faster and eas ier replacement of defective power cables on the jobsite — compatible with other selected Hilti tools we want to hear from you Order information Description Item number TE 3000-AVR 2229035 Performance package 374 014 4 Technical data Working direction Floor Tool chuck type TE-H Weight according EPTA Procedure 01/2003 - 59.8 lbs Single impact energy 62.7 ft-lbs Full hammering frequency 860 impacts/min Triaxial vibration for chiseling into concrete 6.7m/s²

722/)/((7 0$1$*(0(17  <($5 :($5$1'7($5 &29(5$*(  <($5 /,0,7(' :$55$17<  '$< 5(3$,5 7851$5281' Tool warranty. Some limitations apply. Contact Hilti for details. Order information Description Item number TE 3000-AVR 2229035 Performance package 374 014 4 Accessories Description Item number TE 3000 Power supply cord 2186609 TE DRS-H Dust removal system 2268007 Inserts Description Line Item number TE-HX SM 40 Pointed chisel 2254657 TE-HX SM 50 Pointed chisel 2254658 TE-HX FM 40 Flat chisel 2 25 4774 TE-HX FM 50 Flat chisel 2254775 TE-HX SC 40/8 Scaling chisel 2254769 TE-HX SC 50/8 Scaling chisel 2254770 TE-HX AC 42/12 Asphalt cutter 2254755 TE-HX AC 50/12 Asphalt cutter 2254757 TE-HX SP 50 Clay spade 2254759 TE-HX RD 2 Ground rod driver 2254762 TE-HX RD 2.5 Ground rod driver 2254763 TE-H SH 40 Chisel shank 2254761 TE-H SM 40 Pointed chisel 2254751 TE-H SM 50 Pointed chisel 2254752 TE-H FM 40 Flat chisel 2254778 TE-H FM 50 Flat chisel 2254779 TE-H SC 40/8 Scaling chisel 2254773 TE-H SC 50/8 Scaling chisel 2254765 Universal detachable cord A multiline portfolio of newly designed TE-H chisels — offering ultimate chisels for the most performance and longest life and premium chisels for the best economical option. CHOOSE THE BEST SOLUTION FOR YOU Ul timate P remium S tandard Ultimate performance for demanding applications Premium performance for a wide range of applications Hilti quality at an economical price

we want to hear from you OPTIMIZED PORTFOLIO, INCREASED LIFETIME TE-YX Hammer drill bits Enjoy faster drilling, more strength and an extended drill bit lifetime with the new generation of TE -YX hammer drill bits. Discover the fully updated portfolio with new 1/2” to 5/8” drill bits and experience the improved lifetime of the ov erall portfolio. The new 1/2” to 5/8” drill bits have up t o 13x more lifetime through rebar versus the previous generat ion, in addition the overall portfolio has increased up to 30% gr eater lifetime in reinforced concrete. Maximize y our H ilti SD S c ombihammer’s performance by utilizing our full portfolio of ham mer dr ill b its. The TE -YX features a wear mark that has you covered. Your bit will be replaced at no charge to you if it breaks, bends or becomes unusable — that’s our commitment t o y ou. APPLICATIONS AND ADVANTAGES • Ultimate SDS Max (TE-YX) hammer d rill bit with full four and six cutter carbide x-geometry head for drilling into reinforced concrete • So lid carbide head for top performance and reliability with less jamming when hitting rebar • He at-treated flute for less wear Six cutter full carbide head

Technical data Connection end TE-Y (SDS Max) Head material Full carbide head Order information Description Item number TE-YX ½” x 13” 2184681 TE-YX ½” x 21” 2184682 TE-YX 9/16” x 13” 2184683 TE-YX 9/16” x 21” 2184684 TE-YX 5/8” x 13” 2184685 TE-YX 5/8” x 21” 2184686 New item numbers Six cutter full carbide head

CUT COSTS AND STAY ON SCHEDULE Hilti Smart service subscription we want to hear from you Help manage variable costs by leveraging our Hilti Smart service subscription. With multiple service tiers at fixed monthly or annual fees, you can select the level of support that is right for your unique business. Take advantage of from your Hilti Smart subscription service with unlimited shipping to your desired delivery locations at the speed you need, as well as complimentary on-demand health and safety eLearning trainings and certifications through Hilti Academy. BENEFIT FROM YOUR HILTI SMART SERVICE Transparency Flexibility Value Manage variable expenses and pay a planned annual or monthly fee for services within your selected t ier. Choose the service tier that is right f or yo ur unique bu siness needs and, as your business changes, H ilti Sm art can ch ange with you. Upgrade, downgrade or cancel at any time. Hilti Smart subscription services start at just $50 a month and contain a variety of Hilti’s superior s ervices.

CLICK HERE to learn more about our subscription options STARTER STANDARD PREMIUM ULTIMATE

ANCHORS SET FOR SUCCESS HIT-HY 200-A/R V3 Adhesive anchor + SafeSet Experience increased anchor durability and performance in concrete and masonry with our next generation adhesive anchor, HIT-HY 200-V3. Through continuous innovation of our adhesive anchor portfolio, the HIT-HY 200-V3 and SafeSet system brings greater reliability and flexibility to the jobsite. Prepared to take on the harshest conditions, HIT-HY 200-V3 provides strength where you need it most. For even easier, faster installation on your jobsites, pair with our SafeSet installation solutions, Hilit’s proven system that helps ensure faster and more reliable installation every time. By automatically cleaning the hole and dispensing proper adhesive volume, SafeSet can save you up to 60 percent of the installation time. we want to hear from you • U ltimate performance in cracked and uncracked concrete with the widest range of anchor elements • F ulfills requirements of the most demanding ICC-ES approvals for seismic applications • I CC-ES approval for grout-filled CMU • T hirty percent higher published loads in more aggressive temperatures for rebar • Rem oves dust easier and leverages new dis pens er technology with Hilti’s SafeSet system to help ensure the proper amount of adhesive is needed for each anchor, minimizing waste • New water filled borehole condition allowed for rebar and threaded rods • Top performance in dry or wet, hot or cold, hamm er-drille d , hollow drill bit drilled, or core dr illed. APPLICATIONS AND ADVANTAGES Order information Description Item number HIT-HY 200-A V3 MC (11.1 fl oz/330 ml) 3778123 HIT-HY 200-A V3 (11.1 fl oz) 1 MC+HDE 500-22 3778124 HIT-HY 200-A V3 (11.1 fl oz) 2 MC+HDE 500-22 3778125 HIT-HY 200-A V3 (11.1 fl oz) 5 MC+HDE 500-22 3778126 HIT-HY 200-A V3 MC (16.9 fl oz/500 ml) 3778127 HIT-HY 200-A V3 (16.9 fl oz) 1 MC+HDE 500-22 3778128 HIT-HY 200-A V3 (16.9 fl oz) 2 MC+HDE 500-22 3778129 HIT-HY 200-A V3 (16.9 fl oz) 5 MC+HDE 500-22 3778130 HIT-HY 200-R V3 MC (11.1 fl oz/330 ml) 3778131 HIT-HY 200-R V3 (11.1 fl oz) 1 MC+HDE 500-22 3778132 HIT-HY 200-R V3 (11.1 fl oz) 2 MC+HDE 500-22 3778133 HIT-HY 200-R V3 (11.1 fl oz) 5 MC+HDE 500-22 3778134 HIT-HY 200-R V3 MC (16.9 fl oz/500 ml) 3778135 HIT-HY 200-R V3 (16.9 fl oz) 1 MC+HDE 500-22 3778136 HIT-HY 200-R V3 (16.9 fl oz) 2 MC+HDE 500-22 3778137 HIT-HY 200-R V3 (16.9 fl oz) 5 MC+HDE 500-22 3778138

Experience increased anchor durability and performance in concrete and masonry with our next generation adhesive anchor, HIT-HY 200-V3. Through continuous innovation of our adhesive anchor portfolio, the HIT-HY 200-V3 and SafeSet system brings greater reliability and flexibility to the jobsite. Prepared to take on the harshest conditions, HIT-HY 200-V3 provides strength where you need it most. For even easier, faster installation on your jobsites, pair with our SafeSet installation solutions, Hilit’s proven system that helps ensure faster and more reliable installation every time. By automatically cleaning the hole and dispensing proper adhesive volume, SafeSet can save you up to 60 percent of the installation time.

we want to hear from you FASTER, S AFER FIRE P ROTECTION CFP-ES E ndo-Shield e ndothermic m at Protect critical cable circuits, fuel lines, communication sys tems and various MEP systems with our high- temperature CFP-ES Endo-Shield endot hermic mat (Endo-shield) for passive fire pr otect ion and experience simplified ins tallation on the jobsite. High f lexibility a nd l ightweight m aterial o f t his endothermic m at p rovides a mo re e fficient s olution for your fire protection needs, especially for small diameter pipes. Endo-Shield’s d ouble-sided p rotective foil makes for cleaner installation, helping r educe su sceptibility t o damage and incorrect installation. Order information Description Qty Item number CFP-ES Hilti Endo-shield 1 roll 2331829 Accessories Description 99 Qty Item number Firestop sealant FS-ONE MAX 20.0 oz foil 20 2101532 CP 606 Firestop sealant 19.6 oz foil red 20 209634 CLICK HERE FOR Technical data Applications • F ire protection of critical infrastructure, circuits and Distributed Antenna Systems (DAS) • F ire protection of cables and conduits • P rotecting fuel oil piping from fire — such as for backup generators • I ncreasing the T rating of conduit, EMT or pipe penetrations — such as through floors in electrical, data or mechanical rooms • F ire protection of large membrane penetrations — such as recessed electrical boxes/panels in rated barriers, fire extinguisher cabinets or medical gas box outlets Advantages • F aster, easier fire protection • H elps to lower total installed cost • S afer jobsites — made using non-carcinogenic LPB fibers, removing a common safety hazard for installers and benefiting complex healthcare building projects • E xtensive third-party performance verification — tested to ASTM E1725 for circuit integrity and UL1489 for fuel pipe protection Hilti Firestop Saving lives through innovation and education APPLICATIONS AND ADVANTAGES

LIGH TWEIGHT F OR Q UICKER INS TAL LATION CS-S SA Light smoke and acoustic sealant Experience faster and more efficient installation with our CS-S SA Light smoke and acoustic sealant (CS -S SA Light). Its best-in-class tooling and dispensing helps you achieve a cleaner finish for sealing joints and penetrations, including some CPVC pipes, in just one pass. Unlike traditional sealants that require great effort to dispense, CS-S SA Light is 4 4% lighter helping decrease installation fatigue during the dispensing process. The low VOCs promote high standar ds for the health a nd s afety o f y ou a nd y our c rew. Order information Description Qty Item number CS-S SA Light smoke and acoustic sealant foil 20 oz 20 2305383 CS-S SA Light smoke and acoustic sealant 5GAL pail 1 2305384 Accessories Description Item number Foil dispenser, pneumatic 3489906 CS 270-PI foil pack manual dispenser 24669 CD 4-A — 20oz barrel (tool only) 3626175 Follow plate 3024002 CD 600-B bulk firestop dispenser 423363 CLICK HERE FOR Technical data APPLICATIONS AND ADVANTAGES Applications • S ealing construction joints in drywall and internal partitions (non fire-rated walls) • S ealing around penetrations for non-fire rated walls, including Lubrizol CPVC pipe • A pproved for bituminous coated cast iron pipe compatibility — please contact Hilti for details Advantages • Ra pid installation — lighter weight allows for easy installation, helping you quickly move on to your next project • FB C™ System Compatible — sealant suitable for a wide range of Lubrizol CPVC pipes and fittings, check with Lubrizol for more information. • M ade in the USA — for shorter lead times and supporting local jobs • L ow VOCs — smoke and acoustic sealant formulated to meet LEED ® V4 project requirements and healthcare industry building standards Hilti Firestop Saving lives through innovation and education

SIMPLIFY CONNECTION DESIGN PROFIS Engineering Suite we want to hear from you DRIVING ACCURACY PROFIS Engineering Suite makes performing analysis of the complete connection including post-installed anchors, base plate, and welds easier. Enabling you to more easily model, calculate and generate reports for the complete connection. minutes/ calculation Save up to 60 PROFIS Engineering Suite is a user-friendly, cloud-based application that helps make designing connections easier for everyone. With PROFIS Engineering, you can design, calculate and analyze multiple connection types, including steel to concrete, steel to masonry and baseplate solutions. PROFIS Engineering Suite is one of the only complete anchor design software on the market that combines all the functionality you need with the features you want. GAME CHANGING FEATURES Export design information directly to 3D models Export anchor and baseplate objects directly into BIM/CAD programs with our REVIT Plug-in. Take advantage of integrated base plate analysis Generate clear reports including realistic baseplate calculations using AISC Design Guide 1 or Component Based Finite Element Analysis in a few easy steps. Intuitive interface User-friendly features created by engineers, for engineers, including a new favorites tab and an undo button for quicker anchor calculation iterations.

B E C D A ≥ 10 min. time savings per design ≥ 60 min. time savings per design ≥ 15 min. time savings per design Import From Structural Analysis Software Design Full Application With PROFIS Engineering Suite Export To BIM/CAD Software A B C E Direct Integration with RISA, STAAD.Pro, SAP200, ETABS and R obot Anchor Design Stiffener Design Base Plate Design D Multiple Load Combinations Multiple Base Materials Excel Import 1 2 3 Direct Plug-In for REVIT and TEKLA Export to CAD A OR OR HOW IT WORKS

we want to hear from you BX Battery-actuated BX 3-ME 02 and pole tool/nail portfolio X-PT B3 X-P 20 B3 MX SI PBH S CRS SS S-MD BX wire hanger BX 3-ME 02 Loop lock DX Powder-actuated DX 351 and pole tool/cartridges Loop lock Channel lock DX 351 M+E DX wire hanger X-PT 351 TE 30 A and SIW 22-A to drill and fasten hangers TE 30 A SIW 22-A MW-LP CL MW-EB CL MVA-Z MW Ceiling clip Install the system to versatile base materials such as concrete, steel, deck, and wood INSTALLATION JUST GOT EASIER Wire hanger system Experience faster, easier installations with Hilti’s new pre-cut wire hanger system. Ideal overhead hanging for spiral and rectangular HVAC ducting and lighting applications, wire hangers can help reduce costs, increase productivity, all while delivering an aesthetically pleasant support solution for your HVAC and electrical jobs. The system works with both battery (BX) and powder-actuated (DX) fasteners, our anchor platform, and comes with loop lock and channel lock. APPLICATIONS AND ADVANTAGES BX wire hanger DX wire hanger Anchor hanger • O verhead hanging of HVAC and electrical system for load capacity up to 30 lbs • F rom floor access with pole tools for extra convenience • I nnovative and unique loop lock with built-in safety nut feature • O nly system that works with a battery actuated fastening tool • O verhead hanging of HVAC and electrical system for load capacity up to 100 lbs • F rom floor access with pole tools for added convenience • A vailable with both loop lock and channel lock • F astener is pre-assembled to the clip • O verhead hanging of HVAC and electrical system for load capacity up to 200 lbs • I nnovative and unique loop lock and channel lock with built-in safety nut • V entilation angles for increased productivity • C ompatible with Hilti anchors • D esign and model within Profis MSE software Technical data BX wire hanger Base material Concrete, concrete on metal deck, steel, wood, deck Length 6ft, 10 ft, 20 ft Diameter 2mm Load value Up to 30 lbs Use with tool BX 3 ME 02 Material Carbon steel Approval UL, ICC DX wire hanger Base material Concrete, concrete on metal deck, steel Length 6ft, 10 ft, 20 ft Diameter 2mm Load value Up to 100 lbs Use with tool DX 351 ME Material Carbon steel Approval UL, ICC Anchor hanger Base material Concrete, concrete on metal deck, steel Length 6ft, 10 ft, 20 ft Diameter 2mm and 3mm Load value Up to 100 lbs Use with tool TE 30 A, SIW 22-A Material Carbon steel Approval UL Use loop lock to make a loop around the object Use channel lock to have interface between strut and wire

BX wire hanger DX wire hanger Anchor wire h anger • Overhead hanging of HVAC and el ectrical system for load capacity up to 30 lbs • Fro m floor access with pole tools for extra convenience • Inn ovative and unique loop lock with built-in safety nut feature • Onl y system that works with a battery actuated fastening tool • Ove rhead hanging of HVAC and electrical system for load capacity up to 100 lbs • Fro m floor access with pole tools for added convenience • Ava ilable with both loop lock and channel lock • Fas tener is pre-assembled to the clip • Overhead hanging of HVAC and el ectrical system for load capacity up to 200 lbs • Inn ovative and unique loop lock and channel lock with built-in safety nut • Ven tilation angles for increased productivity • Com patible with Hilti anchors • Des ign and model within Profis MSE software Technical data BX wire hanger Base material Concrete, concrete on metal deck, steel, wood, deck Length 6ft, 10 ft, 20 ft Diameter 2mm Load value Up to 30 lbs Use with tool BX 3 ME 02 Material Carbon steel Approval UL, ICC DX wire hanger Base material Concrete, concrete on metal deck, steel Length 6ft, 10 ft, 20 ft Diameter 2mm Load value Up to 100 lbs Use with tool DX 351 ME Material Carbon steel Approval UL, ICC Anchor wire h anger Base material Concrete, concrete on metal deck, steel Length 6ft, 10 ft, 20 ft Diameter 2m m and 3mm Load value Up to 100 lbs Use with tool TE 30 A, SIW 22-A Material Carbon steel Approval UL Order information BX/DX Lock Description Type Length Nail Qty Item number Loop lock X-MW MX L 6ft/2m BX wire hanger in 2mm diameter 6 ft MX 30 pc 2325727 X-MW MX L 10ft/3m 10 ft MX 30 pc 2325728 X-MW MX L 20ft/6m 20 ft MX 20 pc 2325729 X-MW ALH27 L 6ft/2m DX wire hanger in 2mm diameter 6 ft 27 (preassembled) 30 pc 2325730 X-MW ALH27 L 10ft/3m 10 ft 27 (preassembled) 30 pc 2325731 X-MW ALH27 L 20ft/6m 20 ft 27 (preassembled) 20 pc 2325732 X-MW ALH32 L 10ft/3m 10 ft 32 (preassembled) 30 pc 2325733 Channel lock X-MW ALH27 CL 6ft/2m 6 ft 27 (preassembled) 30 pc 2325734 X-MW ALH27 CL 10ft/3m 10 ft 27 (preassembled) 30 pc 2325735 X-MW ALH27 CL 20ft/6m 20 ft 27 (preassembled) 20 pc 2325736 X-MW ALH32 CL 10ft/3m 10 ft 32 (preassembled) 30 pc 2325737 Order information DX Lock Description Type Length Qty Item number Loop lock MW-EB 1/4 L 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331640 MW-EB 1/4 L 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331641 MW-EB 1/4 L 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331642 MW-EB 3/8 L 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331646 MW-EB 3/8 L 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331647 MW-EB 3/8 L 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331648 MW-LP L 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331652 MW-LP L 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331653 MW-LP L 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331654 MW-LP L 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331658 MW-LP L 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331659 MW-LP L 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331660 Channel lock Clip MW-C - - 50 pc 2287563 MW-EB 1/4 CL 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331643 MW-EB 1/4 CL 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331644 MW-EB 1/4 CL 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331645 MW-EB 3/8 CL 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331649 MW-EB 3/8 CL 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331650 MW-EB 3/8 CL 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331651 MW-LP CL 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331655 MW-LP CL 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331656 MW-LP CL 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331657 MW-LP CL 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331661 MW-LP CL 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331662 MW-LP CL 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331663 MVA-ZP - - 25 pc 4114 9 9 MVA-Z - - 50 pc 3 86532

STAY ON TRACK, STAY CONNECTED ON!Track 3.0 Utilizing a dedicated asset management software to control things like tools, equipment and jobsite materials, ON!Track provides instant clarity and efficiency to your business, and helps reduce operational and overhead costs. ON!Track 3.0 was rebuilt and reimagined based on customer feedback to deliver a significantly improved user experience plus several new features to help further boost productivity. CLICK HERE to unlock access to more information ON!TRACK 3.0 FEATURES Quickly check your inventory and track your tools and equipment with Proactive Tracking Gateways Warehouse 2 Not found 3 Expected assets with active tag 6 Found 3 Unexpected 1 Quantity item management at your fingertips Optimize your tool crib with data driven insights developed to maximize your tool crib productivity Manage your jobsite costs with cost reporting you can customize by specific asset, job, and time period Easily access service, maintenance, and certification records and set alerts to help you stay compliant ON!Track Enhanced sensor tags deliver transparency on how, when, and where your assets are used Integrate the software you already use with ON!Track to exchange data via our Application Programming Interfaces (APIs)

SEND AND RECEIVE WHAT YOU NEED ON!Track 3.0 Field Request Module Send your requests for assets you need on site with a click of a button. ON!Track 3.0 offers the Field Request Module to simplify your requesting process and allow for warehouse managers to reserve necessary tools for you and your crew onsite. When you need the right tool for the job, create your list with the Field Request Module and send over your request within the ON!Track 3.0 application, giving you the autonomy you need to keep your job moving. Our software will produce a receipt for you to stay up to date on all your past and present requests. we want to hear from you HOW IT WORKS Field Request Add assets and desired quantities to the Field Request on your mobile device using Search , Filter or Scan item and add it to the Field Request Receive Field Request alert — In-App and/or Email Download the Field Request attachment Submit Submit request to Receiver with request date Accept / Forward / Decline Field Request Print list and pick requested items in the warehouse Other features • C lone existing Request from history • Forward Request • Remove Request • Re view Request History Send status update on request header level Create Transfer Cart and transcribe requested items Create a new Field Request (on Mobile App) Fulfill the Field Request (on Web) Processes performed by the crib manager A B C 12 20 15

DBS • 01/22 Hilti, Inc. Legacy Tower, Suite 1000 7250 Dallas Parkway | Plano, TX 75024 www.facebook.com/HiltiNorthAmerica www.hilti.com Customer Service: 1-800- 879-8000 Hilti (Canada) Corporation 2201 Bristol Circle, Suite 700 Oak ville, ON L6H 0J8 www.fac ebook.com/HiltiNorthAmerica www.hilti.ca Customer Service: 1-800-363-4458
