BX wire hanger DX wire hanger Anchor wire h anger • Overhead hanging of HVAC and el ectrical system for load capacity up to 30 lbs • Fro m floor access with pole tools for extra convenience • Inn ovative and unique loop lock with built-in safety nut feature • Onl y system that works with a battery actuated fastening tool • Ove rhead hanging of HVAC and electrical system for load capacity up to 100 lbs • Fro m floor access with pole tools for added convenience • Ava ilable with both loop lock and channel lock • Fas tener is pre-assembled to the clip • Overhead hanging of HVAC and el ectrical system for load capacity up to 200 lbs • Inn ovative and unique loop lock and channel lock with built-in safety nut • Ven tilation angles for increased productivity • Com patible with Hilti anchors • Des ign and model within Profis MSE software Technical data BX wire hanger Base material Concrete, concrete on metal deck, steel, wood, deck Length 6ft, 10 ft, 20 ft Diameter 2mm Load value Up to 30 lbs Use with tool BX 3 ME 02 Material Carbon steel Approval UL, ICC DX wire hanger Base material Concrete, concrete on metal deck, steel Length 6ft, 10 ft, 20 ft Diameter 2mm Load value Up to 100 lbs Use with tool DX 351 ME Material Carbon steel Approval UL, ICC Anchor wire h anger Base material Concrete, concrete on metal deck, steel Length 6ft, 10 ft, 20 ft Diameter 2m m and 3mm Load value Up to 100 lbs Use with tool TE 30 A, SIW 22-A Material Carbon steel Approval UL Order information BX/DX Lock Description Type Length Nail Qty Item number Loop lock X-MW MX L 6ft/2m BX wire hanger in 2mm diameter 6 ft MX 30 pc 2325727 X-MW MX L 10ft/3m 10 ft MX 30 pc 2325728 X-MW MX L 20ft/6m 20 ft MX 20 pc 2325729 X-MW ALH27 L 6ft/2m DX wire hanger in 2mm diameter 6 ft 27 (preassembled) 30 pc 2325730 X-MW ALH27 L 10ft/3m 10 ft 27 (preassembled) 30 pc 2325731 X-MW ALH27 L 20ft/6m 20 ft 27 (preassembled) 20 pc 2325732 X-MW ALH32 L 10ft/3m 10 ft 32 (preassembled) 30 pc 2325733 Channel lock X-MW ALH27 CL 6ft/2m 6 ft 27 (preassembled) 30 pc 2325734 X-MW ALH27 CL 10ft/3m 10 ft 27 (preassembled) 30 pc 2325735 X-MW ALH27 CL 20ft/6m 20 ft 27 (preassembled) 20 pc 2325736 X-MW ALH32 CL 10ft/3m 10 ft 32 (preassembled) 30 pc 2325737 Order information DX Lock Description Type Length Qty Item number Loop lock MW-EB 1/4 L 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331640 MW-EB 1/4 L 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331641 MW-EB 1/4 L 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331642 MW-EB 3/8 L 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331646 MW-EB 3/8 L 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331647 MW-EB 3/8 L 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331648 MW-LP L 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331652 MW-LP L 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331653 MW-LP L 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331654 MW-LP L 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331658 MW-LP L 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331659 MW-LP L 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331660 Channel lock Clip MW-C - - 50 pc 2287563 MW-EB 1/4 CL 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331643 MW-EB 1/4 CL 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331644 MW-EB 1/4 CL 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331645 MW-EB 3/8 CL 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331649 MW-EB 3/8 CL 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331650 MW-EB 3/8 CL 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331651 MW-LP CL 2.0 6ft/2m 2mm diameter 6 ft 30 pc 2331655 MW-LP CL 2.0 10ft/3m 2mm diameter 10 ft 30 pc 2331656 MW-LP CL 2.0 20ft/6m 2mm diameter 20 ft 20 pc 2331657 MW-LP CL 3.0 6ft/2m 3mm diameter 6 ft 30 pc 2331661 MW-LP CL 3.0 10ft/3m 3mm diameter 10 ft 30 pc 2331662 MW-LP CL 3.0 20ft/6m 3mm diameter 20 ft 20 pc 2331663 MVA-ZP - - 25 pc 4114 9 9 MVA-Z - - 50 pc 3 86532
