Innovation Magazine Summer 2021 – US

INNOVATION July 2021 SOLUTIONS DESIGNED FOR THE FUTURE

we want to hear from you INSIDE THIS ISSUE

DGH 150 Concrete grinder + cup wheels DWS 225 Orbital drywall sander DD 250-CA Diamond Core Drill DD AF-CA H/L Auto feed DSW 1510-CA Wire saw DSW 2005-TS Wire kit VC 150-6 X/XE and VC 150-10 X/XE Second generation wet/dry vacuum X-IE-GS Insulation fasteners EXO-O1 Exoskeleton AI T320 ON!Track sensor tag HSE Tool Use Tips 722/)/((7 0$1$*(0(17 Hilti Tool Fleet Management Hilti Tools on Demand GRINDING & SANDING DIAMOND CORING CUTTING & SAWING VACUUMS FASTENING SAFETY & SERVICES

we want to hear from you THE NEW STANDARD FOR PROFESSIONAL GRINDING DGH 150 Concrete grinder + Diamond cup wheels Twenty years of continuous development has lead to this, the new DGH 150 concrete grinder has undergone significant upgrades for tackling the most demanding concrete grinding jobs. We also improved the tool’s life to last up to ten times longer and deliver up to a 100% higher removal rate than standard angle grinders. The DGH 150 delivers first-rate ergonomics for heavy-duty handheld grinding, an outstanding material removal rate, superior control, more comfort, and nearly dust-free dry concrete grinding all backed by our industry leading 20-2-1 warranty. Combine all these enhancements with the newly optimized 6” diamond cup wheels to experience increased material removal rate, greater labor efficiency, and best-in-class grinding performance. APPLICATIONS AND ADVANTAGES • Perfect as a compliment for walk-behind grinders for flooring applications, freshly poured concrete in warehouses or tilt-up walls, ideal in municipal water treatment facilities, pool refinishing, heavy demolition, bridges, and anywhere professional grinding is done • Concrete grinder for heavy-duty grinding or roughening of concrete and removing paint, coatings, and epoxy • Dust-resistant brushless motor — helping the concrete grinder last up to 10x longer than a conventional grinder with a brushed motor • Ergonomics optimized for comfort — redesigned head grip designed for control and comfort during floor applications, plus easier gear selection • Digital enhancements — digital lock-on switch and speed selector • Enhanced safety — Quick-stop almost immediately stops the cup wheel spinning once the trigger is released • Virtually dust free — integrated dust hood with edge opening and height adjustment help to curb airborne dust on your jobsites 722/)/((7 0$1$*(0(17  <($5 :($5$1'7($5 &29(5$*(  <($5 /,0,7(' :$55$17<  '$< 5(3$,5 7851$5281' Tool warranty. Some limitations apply. Contact Hilti for details. Lock-on switch/speed selector buttons

APPLICATIONS AND ADVANTAGES • Ergonomics optimized for comfort — redesigned head grip designed for control and comfort during floor applications, plus easier gear selection • Digital enhancements — digital lock-on switch and speed selector • Enhanced safety — Quick-stop almost immediately stops the cup wheel spinning once the trigger is released • Virtually dust free — integrated dust hood with edge opening and height adjustment help to curb airborne dust on your jobsites Order information Description Item number TOOL DGH 150 diamond grinder 2232387 DUST CONTROL VC 150-6X Vacuum 3721395 VC 150-10X Vacuum 2220086 Choose the best diamond cup wheel for the job and experience maximum performance from your DGH 150. Diamond cup wheel order information Description Legend Item number Diamond cup wheel 6” SPX universal ① 2270778 Diamond cup wheel 6” SPX (6) universal ① 2270779 Diamond cup wheel 6” SP (2) universal ② 2270824 Diamond cup wheel 6” SP (6) universal ② 2270777 Diamond cup wheel 6” SPX fine finish ③ 2270820 Diamond cup wheel 6” SPX coatings ④ 2270821 Diamond cup wheel 6” SPX epoxy ⑤ 2270822 Diamond cup wheel 6” SPX abrasive ⑥ 2270823 ⑤ ① ② ④ ③ ⑥ SPX SP Ultimate Premium Ultimate performance for demanding applications Premium performance for a wide range of applications

722/)/((7 0$1$*(0(17 Order information Description Item number DWS 225 Orbital drywall sander 2305388 Accessories Description Legend Item number DWS cable 120V  2314554 DWS 225 extension 50cm  2301717 DWS soft bag  2301716 VC 150-6XE Vacuum 372139 VC 150-10XE Vacuum 3721394 A NEARLY EFFORTLESS LEVEL 5 FINISH DWS 225 Orbital drywall sander With superior ergonomics, class-leading dust control, and a user friendly design, Hilti’s new DWS 225 orbital drywall sander is the ideal tool for level 5 finishes on drywall and for removing paints, adhesives, coatings, and residue. The DWS 225 is a lightweight, long-neck sander with an ergonomic design, better balance, and nearly 180° flexibility, giving you the comfortable control you need when sanding walls, ceilings, and into corners. When paired with Hilti’s mesh net sanding discs, experience virtually dust-free sanding which will help prolong the life of the tool, reduce dust exposure, and minimize cleanup. Inserts Description Legend Item number DWS backing pad  2312472 DWS 225 P80 grit sanding disc  2305500 DWS 225 P120 grit sanding disc  2305502 DWS 225 P150 grit sanding disc  2305503 DWS 225 P180 grit sanding disc  2305504 DWS 225 P240 grit sanding disc  2305506 DWS sanding disc interface pad  23174 5 0 we want to hear from you APPLICATIONS AND ADVANTAGES Applications • Finishing drywall ceilings and floors — included long-neck extension helps avoid using ladders or scaffolds • Sanding drywall, gypsum, and plasterboard filler — variable speed motor gives better control over surface finish and removal rate • Surface preparation — removes drywall compound Advantages • Easier to use — requires minimal practice and rework to help achieve a perfectly smooth drywall finish • Brushless and variable speed motor — better control over surface finish and removal rate and nearly maintenance free for easier on-site servicing       Pair with Hilti’s mesh net sanding discs for virtually dust-free sanding. 

DIAMOND WIRE SAW — EXPAND YOUR CAPABILITIES DSW 2005-TS Wire kit Easily convert the DST 20-CA wall saw to a portable wire saw with the DSW 2005-TS wire conversion kit. When your next project calls for small to medium duty diamond wire sawing, utilize the DSW 2005-TS wire conversion kit with your existing DST 20-CA wall saw. Maintain complete control with your DST WRC-CA wireless remote, which allows for easier operation at a safer distance. APPLICATIONS AND ADVANTAGES • Operator can work untethered from tool with wireless remote to increase safety and mobility • Compatible with DST 20-CA wall saw to convert it to a diamond wire saw • Ready to tackle small to medium wire sawing jobs Pairs with the DST 20-CA wall saw and DST WRC-CA wireless remote DST 20-CA Technical data Dimensions (LxWxH) 33.9” x 27.6” x 92.5” Capacity, wire storage 18.4’ Total weight without saw head 231.5 lb Order information Description Item number DSW 2005-TS wire saw kit 23174 51 Accessories Description Item number DST 20-CA 3x400V PR wall saw 2120304 DST 20-CA 3x400V EC wall saw 2120309

CUT THROUGH WITH CONFIDENCE DSW 1510-CA Wire saw Detach yourself and stay in control with the DSW 1510-CA wire saw, designed to deliver the highest cutting productivity for heavy sawing applications. Steered with a wireless remote control, the DSW 1510-CA provides added operator safety and control, increasing productivity on the jobsite. Leveraging Hilti’s CutAssist technology, the DSW 1510-CA’s wireless remote control, higher starting torque, and maximized performance and power, combined with the existing pneumatic tensioning system allows the DSW 1510-CA to tackle any sawing job. APPLICATIONS AND ADVANTAGES Applications • Sawing anything from heavily reinforced concrete to thick stonework or structural alterations to buildings or infrastructure • Demolition of structural components — such as bridges, chimneys, tunnels, dams, and foundations • Sawing in noise-sensitive locations Advantages • Electric box integrated — no extra cables needed • Higher initial torque to get the wire started • Keyless adjustment of the guide pulleys Technical data Drive dimensions (LxWxH) 33.9 x 27.6 x 92.5 in Weight 761 lb Net wire storage capacity 32.1 f t Order information Description Item number DSW 1510-CA wire saw 3697329

OPE R ATOR SAFETY with a wireless remote control

we want to hear from you DIAMOND DRILLING MADE EASY DD 250-CA Diamond core drill Designed to create an improved core drilling experience, the DD 250-CA diamond core drill makes diamond drilling easier. With its intuitive color digital display, the DD 250-CA diamond core drill provides the operator guidance for proper drill setup, real time drilling feedback, and valuable productivity data once the drilling is complete. The new DD 250-CA also features Bluetooth connectivity that steers the WMS 100 BLE water management system as well as the new DD AF-CA H auto feed unit. Leverage the DD 250-CA on your next jobsite for ultimate productivity. 722/)/((7 0$1$*(0(17 APPLICATIONS AND ADVANTAGES • Unmatched range for all applications • Enables the customer to leverage automation to help make their job easier • New color digital display with step-by-step user guidance, provides usage statistics to help guide less experienced users • Leverage the DD AF-CA H auto feed unit for the new DD 250-CA — you can also utilize the DD AF-CA L auto feed unit with the DD 150-U diamond core drill

Order information Description Legend Item number DD 250-CA BL diamond core motor ① 3731688 Accessories Description Legend Item number DD-HD 30 drilling stand 2159830 WMS 100 BLE Water Management System 3679407 Core rig mounting kit 5/8” 3577074 DD AF-CA H 120V autofeed unit ② 2 24 0 511 Technical data Diameter range 15/ 32”-19’-11/ 16” Base material Concrete, masonry Operation mode Rig-mounted Number of gears 4 No load RPM Gear 1 – 240 RPM Gear 2 – 580 RPM Gear 3 – 1160 RPM Gear 4 – 2220 RPM Weight according to EPTA-Procedure 01/2003 34 lb Weight of complete system 81.4 lb Dimensions (LxWxH) 24.8 x 7.5 x 8.5 in A-weighted emission found pressure level 93 dB (A) ① ② The DD 250-CA paired with the DD AF-CA H makes diamond drilling easier with guidance and automation

we want to hear from you GUIDANCE AND AUTOMATION ON THE JOBSITE DD AF-CA H/L Auto feed APPLICATIONS AND ADVANTAGES • The DD AF-CA H/L units have a sensor in the base material that triggers the drill into start mode before switching to full power • As drilling continues, the right amount of pressure is applied throughout the drilling process • The DD AF-CA H/L also detects when the bit has completed drilling into an opening and automatically retracts the bit to power down the drill process Technical data Dimensions (LxWxH) 6.9 x 5.4 x 12.8 in Weight 9.3 lb Order information Description Item number DD AF-CA H 120V auto feed unit 2 24 0 511 DD AF-CA L 120V auto feed unit 2240485 Accessories Description Item number DD 250-CA BL Diamond core motor 3731688 722/)/((7 0$1$*(0(17 Level up your coring with Hilti’s CutAssist technology using the DD AF-CA H and DD AF-CA L auto feed units on your next project. Designed to improve your jobsite productivity, the DD AF-CA H and DD AF-CA L bring Hilti CutAssist technology to our most popular core rigs, the DD 250-CA and the DD 150-U diamond core drills. When paired with the corresponding diamond core drill, the DD AF-CA units give the operator a semi- autonomous experience to diamond drilling by intuitively guiding the drill through the entire process. Compatible with DD 250-CA Compatible with DD 150-CA

FASTER FASTENING TO COLD-FORMED STEEL X-IE-GS Insulation fasteners Built to make insulation fastening to metal studs easier, X-IE-GS insulation fasteners to cold-formed steel studs deliver up to three times faster application speeds than traditional methods. The preassembled washer and nail in the X-IE-GS provides consistent quality and helps allow for proper installation every time with the pull of the trigger — little to no need for rework. With simpler application to help reduce complexity and labor hours, the X-IE-GS’s higher fastening quality and more intuitive design also provides increased safety on the jobsite. • Only direct fastening solution for installing insulation boards and mineral wool directly to steel studs with sheathing • Hybrid helical knurling provides better stick rate to the metal studs with the speed of a gas actuated nail • The X-IE-GS allows you to use the GX-IE tool for attaching insulation to metal studs, in addition to concrete Technical data X-IE-GS BODY / PLATE Material HDPE, UV stabilized Diameter 2.36” X-GS 57 NAIL Carbon steek shank HRC 57.5, dia. = 0.118” FASTENING PATTERN, EDGE DISTANCE AND SPACING ON INSULATION MATERIALS Fastened material Rigid mineral wool EPS, XPS, PIR, PUR, PIR/PUR with foil facing Min. number of fasteners per sq. ft. 0.6 Pattern, edge distance and spacing Follow insulation board manufacturers’ recommendations Order information Description Item number X-IE-GS 1 2299884 X-IE- GS 1-1/2 2293071 X-IE-GS 2 2293072 X-IE- GS 2-1/2 2293073 X-IE-GS 3 2293074 X-IE- GS 3 -1/2 2299885 X-IE-GS 4 2293075 Accessories Description Item number GX-IE tool 2210319 Fastener guides 2210569 XL conversion kits 2210570 APPLICATIONS AND ADVANTAGES

CONSTRUCTION SAFETY Building a safer jobsite for you and your crew Helping ensure greater health and safety for you and your crew will always be a top priority. As Hilti continues to invest in product trainings, application research centers, integrated technology, and ergonomics, we remain committed to delivering better, more reliable safety solutions for your crew. Together, we strive to support a safer jobsite and industry for construction workers — starting with tips on operational safety for different tools. It’s just one more way Hilti is there for you, from start to finish. we want to hear from you CONCRETE BREAKING When working with concrete on the jobsite, accidents can occur when operators lose focus. It is important to stay vigilant and keep safety top of mind while breaking concrete. • Inspect the tool before operation to ensure it is in good working condition and not damaged. If damaged or not functioning properly, discontinue use until it is fixed • Ensure everyone wears appropriate personal protection such as eye protection, a hard hat, hearing protection, dust protection, safety shoes and gloves • Stay alert, watch what you are doing and use common sense when operating a power tool DECKING While decking has traditionally been done with fastening tools, new stand up decking power tools allow for work to be done with greater comfort and convenience. • Mark the deck before firing — this helps ensure that the under beam is hit, thereby reducing the chance of fragments, blow throughs, and/or damage to the tool • Keep the grips dry, clean and free of oil and grease • Wear suitable eye protection, a hard hat, ear protection and protective gloves while the tool is in use and ensure others in the vicinity do the same Click here for more information on health and safety

GAS-ACTUATED FASTENING Minimize injuries by taking advantage of gas- actuated tool training programs provided by tool manufacturers and user safety awareness. • Only those trained in the use of gas-actuated fastening tools (or under direct supervision by a trained operator) should use this equipment • Hold the setting tool only by the insulated grip when working in areas where fasteners may be driven inadvertently into concealed electrical cables • Before driving fasteners, check there is no risk of injuring anyone or of damaging objects present behind or below the working surface TOOL TETHERS Tool tethers are a simple and effective way to help prevent injuries or even fatalities from dropped tools. The following must be considered when selecting the correct tethering setup: • The weight of the tool — including batteries, accessories, inserts, etc. — to be tethered. Check the weight capacity on the tether tag to ensure the capacity of the tether will not be exceeded • Ensure there is a solid point on the tool where the tether can be firmly attached, and attach the tether

we want to hear from you POWERFUL, COMPACT, MOBILE VC 150-6 X/XE and VC 150-10 X/XE Second generation wet/dry vacuum Make clean up easier with smart wet/dry vacuum technology. Developed to provide more performance, the second generation VC 150 X and XE vacuums have been enhanced to help give you better mobility around the jobsite. Both VC 150 X and XE versions are now smarter than ever. The integrated self-diagnosis function and new interface provide the user with continuous updates on the status of the vacuum cleaner, helping to make maintenance easier and providing clarity on when the filters need to be changed. The VC 150-10 X/XE vacuums maintain large net capacity, offering the right solution for dust heavy applications. The VC 150-6 X/XE vacuums are the perfect solution for when you need a compact and lightweight vacuum. APPLICATIONS AND ADVANTAGES • Greater mobility — the big wheels and push- bar of the VC 150-10 allows for better mobility • Smarter than ever — the vacuum cleaner self diagnoses and informs the user of the status and when the filter needs to be replaced • High volume flow rate — the second generation VCX 150s have a driving high volume flow rate of 156 CFM Order information Description Legend Item number VC 150-6 X 120V ① 3721395 VC 150-10 X 120V ② 2220086 VC 150-6 XE 120V ③ 3720112 VC 150-10 XE 120V ④ 3721394 Accessories Description Item number VC 20/40/150 Standard filter dry 2278640 VC 20/40/150 Premium filter universal 2261257 VC 20/40/150 Ultimate filter HEPA 2261452 VC 20/150-6 Premium dust bag fleece 2261258 VC 40/150-10 Premium dust bag fleece 2262130 VC 20M Ultimate dust bag plastic 2261451 VC 40M Ultimate dust bag plastic 2262095 VC accessory storage bag 2271512 VC 20 shoulder strap 2276922 Technical data CFM 156 Capacity VC 150-6 X/XE: 4 gal VC 150-10 X/XE: 8 gal IP protection class IP X4 EXCLUSIVELY DESIGNED ACCESSORIES  X Vacuums VC 150-6 X and VC 15 0 -10X

722/)/((7 0$1$*(0(17  <($5 :($5$1'7($5 &29(5$*(  <($5 /,0,7(' :$55$17<  '$< 5(3$,5 7851$5281' Tool warranty. Some limitations apply. Contact Hilti for details. ② ③ ④ XE Vacuums VC 150-6 XE and VC 150-10 XE X Vacuums VC 150-6 X and VC 15 0 -10X

Order information Description Item number EXO-O1 overhead exoskeleton HA 2329421 Accessories Description Item number EXO-O1 arm pad HA 2281865 EXO-O1 comfort arm pad HA 2283254 EXO-O1 adjustment clip and wheel HA 2281866 EXO-O1 hip belt extender HA 2281864 EXO-O1 bag HA OVERHEAD WORK REINFORCED EXO-O1 Exoskeleton Hilti now offers the EXO-O1 Exoskeleton as a pioneering solution to improve jobsite efficiency and help alleviate upper-body fatigue and pain resulting from repetitive overhead tasks. we want to hear from you

The EXO-O1 leverages passive exoskeleton technology (mechanical expanders) that is intuitive, easy-to-adjust, well-balanced, lightweight, and offers a virtually unimpeded range of motion. Bringing greater safety and comfort to demanding applications like overhead drywall, piping, air duct, cables and conduit installation among others, the EXO-O1 prioritizes safety and productivity. There has never been greater focus to improve health, safety, and efficiency on the jobsite. Let Hilti’s EXO-O1 Exoskeleton help you redefine the way you safely and effectively tackle overhead work today. 722/)/((7 0$1$*(0(17 $66(7 0$1$*(0(17 75$&. 21  <($5 :($5$1'7($5 &29(5$*(  <($5 /,0,7(' :$55$17<  '$< 5(3$,5 7851$5281' Tool warranty. Some limitations apply. Contact Hilti for details. APPLICATIONS AND ADVANTAGES Applications • Ideal for tasks where at least 60% of time is spent working overhead • Installing overhead air ducts and ventilation equipment • Installing overhead sprinklers • Installing overhead piping • Installing overhead cables and conduits • Hanging drywall board Advantages • All-day comfort — weighing under 4.4 lbs, this ultralight exoskeleton can help delay arm/shoulder muscle fatigue during long periods of overhead work • Freedom of movement — provides dynamic support without restricting the range of motion of arms and torso • Versatile — engineered to provide support for virtually any overhead installation work on construction jobsites • No batteries needed — no power source to charge and no motors to maintain help ensure your overhead exoskeletons are ready whenever you need them CLICK HERE to learn more

BETTER, SMALLER, SMARTER The next generation AI T320 ON!Track sensor tag SMARTER Valuable insights on assets’ usage thanks to sensing capabilities SMALLER Improved attachability even to smaller assets LONGER BATTERY LIFETIME 4 years in 73° F (moderate climate) Warehouse 2 Not found 3 Expected assets with active tag 6 Found 3 Unexpected 1 FASTER ACTIVATION Activation possible with iOS and Android devices With the newest AI T320 ON!Track sensor tag, you’ll gain more transparency to your tool crib than ever before. The smarter, longer lasting, and more compact tag allows you to identify underutilized tools to help you redistribute them where they’re needed most. CLICK TO LEARN MORE ABOUT ON!TRACK. All tools and equipment can be tagged with ON!Track smart tag ON!Track

Tool begins in Tools on Demand cen ter 1 Customer places order for tool 2 Tool used at jobsite for 3-12 months 3 4 Customer request s shipping label when done using tool Tool shipped bac k via Purolator 5 Tool arri ves at Tool Servic e Center for che ckup and refresh 6 Tool is returned to our warehouse until you need it again 7 TOOLS WHEN AND WHERE YOU NEED THEM Tool Fleet Management and Tools on Demand TOOLS ON DEMAND The flexibility to tool up or tool down to meet peak demands Small tool needs can fluctuate by job and with Hilti’s Tools on Demand (TOD) program through your Fleet account, you get the flexibility to tool up or tool down to meet peak demands. Minimize your total tool spend in real dollars and eliminate soft costs of moving tools from site to site. CLICK HERE to learn more TOOL FLEET MANAGEMENT Manage your tools and your costs With Hilti’s Tool Fleet Management, you can minimize many of the headaches and expenses associated with managing the tools you need to get the job done. Optimize your tool crib with Hilti’s Tool Services solutions so you can keep your people, projects, and business running at peak performance. Our teams are ready to help consult with you on ways to help improve jobsite safety and productivity without the burden of a major upfront investment.
